DIGIBASE Disc Filter Black 10 micron Luer - 8111-33-0010B-23

This black last chance filter is suitable for Mimaki TS500-1800 printers.

Specifications

• Type: Disc Last Chance Filter (LCF)
• Pore Size: 10 micron
• Inlet connection: Female Luer-Lock compatible (double helix)
• Outlet connection: Female Luer-Lock compatible (double helix)
• Disc diameter: 45mm (1.77")
• Disc width: 9mm (0.35")
• Maximum Operating Pressure: 5 barg / 72.5 psig @ 20 °C / 68 °
• Operating temperature: From 0°C to 50°C (32°F to 122°F)
• Use: Air / Liquid
• Solvent resistant: Yes
• UV resistant: Yes

***Double Helix uses 2 spirals, one that makes the connection, and one that secures the connection.
